30" Flexible Roller Conveyors

Speedrack West | SKU: CV-FRC-30-5-8

$5,093.07

Shipping calculated at checkout.

Length Variants

8 ft. 12 ft. 16 ft. 24 ft.

Handling & Use Requirements

Equipment must be used within rated load capacities and installed on suitable warehouse flooring. Improper loading, uneven distribution, or use outside intended applications can result in structural failure.

Inspect all shipments upon delivery and note any freight damage before signing. Installation and final configuration should be verified by qualified personnel to ensure safe operation.

Delivery & Freight Shipping

All equipment ships via LTL or dedicated freight carriers and is delivered curbside or dock-high depending on facility setup. Liftgate service is not included unless specifically requested at the time of quote.

You are responsible for unloading the shipment and must have appropriate equipment (forklift or dock access) available at delivery. Failure to meet delivery requirements may result in re-delivery fees.

Inspect all items upon arrival before signing the Bill of Lading. Any visible damage must be noted at delivery—claims cannot be processed after acceptance without documentation.

Lead times vary based on product type, configuration, and supplier availability. You will receive confirmation of estimated ship dates after order review.

Add a stand out message for your customers

Need Help Specifying This Equipment?

Call (888) 620-0190 or email support@kgwarehouseequipment.com. Our team will confirm system fit, capacity, and compatibility before you place an order.

Description

Flexible Roller Conveyors for Portable Loading and Unloading Applications

30" Flexible Roller Conveyors are portable, expandable material-handling systems designed for loading docks, packaging stations, shipping areas, ecommerce fulfillment, assembly lines, and temporary workflows. The adjustable design allows easy repositioning while maintaining smooth carton flow. Built with heavy-duty steel, reinforced side links, and welded supports, these conveyors handle cartons, totes, and packaged goods in demanding warehouse environments. Ideal for temporary or flexible operations, but not intended for pallet handling or high-speed automation lines.

Best Applications for 30" Flexible Roller Conveyors

Warehouse loading and unloading operations
Ecommerce fulfillment centers
Packaging and shipping lines
Assembly and inspection workstations
Temporary conveyor extensions
Cross-docking workflows
Parcel and carton movement between work areas
Mobile warehouse conveyor applications

Key Features of the 30" Flexible Roller Conveyor

Expandable 3:1 Conveyor Design: The flexible conveyor design expands and contracts as operational requirements change, allowing the system to be repositioned between loading, unloading, and packaging areas while minimizing storage space when not in use.
5" Roller Centers: Tight roller spacing improves support for smaller cartons, totes, and packaged products while maintaining smoother product flow across the conveying surface.
1.5" Diameter Rollers: Heavy-duty rollers are designed for continuous movement of cartons and packaged materials commonly found in warehouse and fulfillment operations.
Adjustable Conveyor Height: Adjustable support legs allow the conveyor height to be modified from 31-1/2" to 42-1/2" to better align with dock heights, packing stations, and conveyor transitions.
Heavy-Duty Mobile Support System: Each conveyor leg includes 6" x 2" casters and integrated handles for repositioning throughout warehouse and shipping environments. Locking casters at the fixed end stabilize the conveyor during operation.
Reinforced Structural Construction: Solid weld leg construction, four-point support connections, and heavy-duty 7 gauge steel side links are designed to withstand repetitive warehouse use and demanding loading dock conditions.
High Load Capacity: The fully expanded conveyor supports loads up to 350 lbs. per foot of conveying surface when evenly distributed.

30" Flexible Roller Conveyor Specifications

Specification	Details
Conveyor Width	30"
Conveyor Type	Flexible Roller Conveyor
Roller Centers	5"
Roller Diameter	1.5" OD
Expansion Ratio	3:1
Adjustable Height Range	31-1/2" to 42-1/2"
Casters	6" x 2" Heavy-Duty Casters
Conveyor Mobility	Portable / Expandable
Side Links	Heavy Duty 7 Gauge Steel
Leg Construction	Solid Welded Supports
Support Connection Type	Four-Point Leg Supports
Capacity	Up to 350 lbs. per ft.
Recommended Product Types	Cartons, Totes, Packaged Goods
Typical Applications	Loading, Unloading, Packaging, Shipping

Available Length Variants

Length	SKU
8 Ft	CV-FRC-30-5-8
12 Ft	CV-FRC-30-5-12
16 Ft	CV-FRC-30-5-16
24 Ft	CV-FRC-30-5-24

Operational Considerations and System Limitations

Flexible roller conveyors are designed for temporary or reconfigurable workflows rather than permanent conveyor infrastructure.
These conveyor systems are intended for cartons, packages, and totes rather than direct pallet transport.
Uneven warehouse floors can reduce conveyor tracking consistency and product flow performance.
Outdoor exposure and wet operating environments will reduce component lifespan if the system is not properly protected.
High-speed automated sortation systems should use fixed powered conveyor solutions instead of flexible conveyor systems.
Conveyor performance depends on product dimensions, product weight distribution, floor conditions, and conveyor layout geometry.

📚 Frequently Asked Questions (FAQs)

Can flexible roller conveyors replace permanent conveyor systems?

No. Flexible roller conveyors are designed for temporary or movable material handling workflows rather than permanent conveyor automation systems.

Are flexible roller conveyors designed for pallet handling?

No. These conveyor systems are intended for cartons, totes, and packaged goods rather than direct pallet transport applications.

What warehouse environments are best for flexible roller conveyors?

Flexible roller conveyors perform best in loading docks, shipping stations, fulfillment operations, and temporary conveyor workflows that require frequent repositioning.

Do flexible roller conveyors work on uneven floors?

Uneven warehouse floors reduce conveyor tracking consistency and product flow efficiency. Smooth warehouse surfaces are recommended for proper operation.

When should a fixed conveyor system be used instead of a flexible conveyor?

Fixed conveyor systems should be used for permanent automation lines, high-throughput sortation systems, and continuous heavy-duty material handling operations.
